- Model: YPSDZ-1600-2000 high-capacity battery tester
- Voltage Range: Supports up to 100V systems
- Current Capacity: 20A charge/discharge capability
- Dual LED Digital Displays: Clear, real-time monitoring of test data
- Active Cooling System: Fan-based thermal management for stable performance
- Clamp Terminals: Secure, heavy-duty battery connections for reliable operation
24S 10AMP ACTIVE BALANCER (NEEY)(352s)
Battery testing and diagnostics during manufacturing or maintenance
✔ Balancing and equalization of large battery packs
✔ Solar energy storage systems
✔ Electric vehicle (EV) battery systems
✔ UPS / inverter battery banks
✔ DIY battery builders and repair shops
24S 14A INTELLIGENT AUTOMATIC EQUALIZER (XY-FD14AS24CK) (5335)
📊 Technical Specifications
| Feature | Details |
|---|---|
| Model | XY‑FD14AS24CK |
| Cell Support | 2S – 24S lithium battery packs |
| Max Equalization Current | Up to 14 A |
| Equalization Modes | Automatic identification modes (discharge/voltage/charge) |
| Balanced Voltage Range | 2.0 V – 4.5 V per cell |
| Protection Features | Reverse polarity, over‑voltage, low‑voltage, misconnection warnings |
| Power Supply | 12 V 5 A external |
| Supported Battery Types | Li‑ion, LiFePO4, LTO, and similar lithium chemistries |
| Interface Voltage Tolerance | ±120 V (B‑ to B24 interface) |
| Display / Monitoring | Typically includes multi‑parameter display or status outputs |
| Modes Requiring Charger | Constant‑voltage and charge balance modes require an external charger with adjustable non‑auto‑stop |
24S 15AMP ACTIVE BALANCER (NEEY)(1255)
📊 Typical Specifications
| Feature | Detail |
|---|---|
| Supported Cell Range | 2S – 24S lithium battery packs |
| Maximum Balancing Current | 15 A |
| Voltage Detection Accuracy | ~1 mV |
| Operating Temperature | −20 °C to +45 °C |
| Balancing Method | Active energy transfer |
| Battery Types Supported | Li-ion, LiFePO₄, and similar chemistries |
24S 4AMP ACTIVE BALANCER (NEEY)(15sa)
📊 Typical Technical Specs
| Feature | Details |
|---|---|
| Model / SKU | 24S 4A Active Balancer (NEEY, 15ee) |
| Balancing Type | Active (energy transfer) |
| Max Balancing Current | 4 A |
| Supported Cells | 24S lithium battery packs |
| Battery Types | LiFePO₄, Li-ion, LiPo, NMC |
| Operating Temp | –20 °C to +60 °C |
| Power Source | Battery pack (self-powered) |
| Protections | Overcurrent & reverse-connection |
24S 5A INTELLIGENT AUTOMATIC EQUALIZER (1501)
📊 Technical Specifications
| Feature | Detail |
|---|---|
| Model | XY-FD04AS24G |
| Supported Cells | 2S – 24S lithium battery packs |
| Balancing Current | Up to 5 A |
| Cell Voltage Range | ~2 V–4.5 V per cell |
| Operating Voltage (Input) | Pack dependent (−100 V to +100 V input terminals) |
| Protection | Reverse polarity, overvoltage, undervoltage alarm |
| Display / Info | Cell voltages, total voltage, avg/max/min voltages, differential |
| Power Supply | 12 V 5A external supply required |
| Mode | Fully automatic equalization |
| Use Case | EV battery packs, ESS, solar backup, large DIY powerwalls |
24S 8A INT. AUTOMATIC EQUALIZER (XY-FD24SCG-7) (5a13)
📊 Technical Specifications (Typical)
| Feature | Details |
|---|---|
| Model | XY-FD24SCG-7 |
| Cell Support | 2S – 24S lithium battery packs |
| Maximum Equalization Current | ~8 A (automatic) |
| Equalization Method | Automatic voltage equalization |
| Protection | Overcurrent & overheating safeguards |
| Design | Compact, lightweight, easy to integrate |
| Applications | EVs, solar storage, high-capacity battery systems |
24S 8AMP ACTIVE BALANCER (NEEY) (se12)
📊 Typical Technical Specifications
| Feature | Details |
|---|---|
| Model / Type | 24S 8 A Active Balancer (NEEY, se12-style) |
| Balancing Current | Up to 8 A |
| Cell Support | 2S – 24S lithium packs |
| Balancing Method | Active energy transfer |
| Battery Chemistries | LiFePO4, Li-ion/NMC, LTO — generally supported |
| Voltage Detection Range | Typically ~1.5 V – 4.5 V per cell |
| Communication / App Support | Often Bluetooth &/or CAN (varies by model) |
| Protections | Reverse polarity, wiring faults, undervoltage alerts |
| Operating Temp. | ~–20 °C to +55 °C (typical) |
BALANCER CONNECT BOARD (24S 4AMP) (5834)
- Voltage: Designed for 24-series battery packs
- Current Rating: 4A maximum
- Function: Balances and monitors individual cell voltages in battery packs
- Applications: Used in lithium-ion battery packs, energy storage, and EV systems
- Material: Durable, heat-resistant construction for reliable performance
- Features: Ensures optimal charge distribution and battery health
- Design: Compact, easy to integrate into battery management systems (BMS)
BALANCER CONNECT BOARD (24S 5AMP) (532s)
- Voltage: Designed for 24-series battery packs
- Current Rating: 5A maximum
- Function: Balances individual cell voltages and ensures even charging
- Applications: Suitable for lithium-ion battery packs, energy storage, and electric vehicles
- Material: Durable, heat-resistant construction for long-lasting reliability
- Features: Protects battery health by optimizing charge distribution
- Design: Compact and easy to integrate into battery management systems (BMS)
BALANCER CONNECT BOARD JK (24S 4AMP) (s55a)
- Supports 2S–24S lithium battery packs
- 4 A active balancing current for faster voltage equalization
- Transfers energy between cells (active balancing)
- Easy connection to BMS balance harness
- Compatible with Li‑ion, LiFePO₄, and similar chemistries
- Ideal for EVs, solar storage, UPS, and DIY battery packs
BATTERY CAPACITY TESTER (YPSDZ-0550-4) (s1ac)
- Model: YPSDZ-0550-4 multi-channel battery discharge tester
- 4 Independent Channels: Simultaneous testing with individual control per channel
- Voltage Range: 0.3V – 5V precision testing
- High Current Output: Up to 50A per channel
- Dedicated LCD Displays: 4 digital screens (one per channel) for real-time monitoring
- Comprehensive Measurements: Voltage, Current, Discharge Time, Capacity (Ah, Wh)
- Discharge Mode: Constant current electronic load for accurate testing
- Input Power: AC 200–240V compatible
- Built-In Safety Protections: Over-voltage, over-current, and short-circuit protection
- Heavy-Duty Clamps: Durable red & black alligator terminals for secure connection
BATTERY CAPACITY TESTER (YPSDZ-1600-2000) (b111)
BATTERY CAPACITY TESTER (YPSDZ-800-1000) (s1aa)
- Model: YPSDZ-800-1000 professional battery charge/discharge tester
- Wide Voltage Coverage: Operates from 1V to 100V
- Flexible Current Settings: Configurable charge/discharge current per battery specifications
- Dual LED Displays: Clear, real-time data monitoring
- Comprehensive Measurements: Capacity (Ah, Wh), Voltage, Current & Internal Resistance
- Multi-Chemistry Compatible: Supports Li-ion, LiFePO₄ (LFP), NMC & Lead-Acid batteries
- Advanced Cooling System: High-speed dual cooling fans for stable operation
- Industrial-Grade Connectivity: Dual output terminals with heavy-duty clamps
BATTERY PACK CAPACITY TESTER (YPSDZ-3010) (b111)
- Model: YPSDZ-3010
- Voltage Range: Up to 30V
- Current Range: Up to 10A
- Charging Mode: Constant Current (CC) / Constant Voltage (CV)
- Discharging Mode: Constant Current
- Display: Digital LCD Screen
- Connection Ports: Aviation Connectors (Positive & Negative)
- Cooling System: Smart Fan Cooling
- Design: Compact Desktop Unit
BATTERY TESTERS DK-BPT50 99V50A (a13s)
- Voltage Range: Up to 99V
- Current Output: Up to 50A per channel
- Channel Count: Multiple independent channels (exact number to be confirmed)
- Battery Compatibility: Supports Li-ion, Polymer, NiMH, NiCd, and Lead-acid batteries
- Operation Method: Online
- Communication Port: LAN (TCP/IP protocol)
- Input Power: AC 200V–245V, 50Hz/60H
BATTERY TESTERS DSF20(DK)99V-20AMP (1d2e)
- Model: DSF20
- Input Voltage: AC 220V ±10%, 50Hz/60Hz
- Input Power: 900W
- Applicable Batteries: Lithium-ion and lead-acid battery packs
- Charge Modes: Constant current and constant voltage
- Discharge Modes: Constant current
- Charge Cut-off Conditions: Voltage, current, time, capacity
- Discharge Cut-off Conditions: Voltage, current, time, capacity
- Cycle Index: 1–16 times
- Data Recording Conditions: Time interval, voltage interval, current interval
- IP Grade: IP20
- Noise Level: <76 dB
- Operating Temperature: 0°C to 40°C
- Storage Temperature: -10°C to 50°C
- Operating Humidity: ≤70% RH (non-condensing)
- Storage Humidity: ≤80% RH (non-condensing)
- Dimensions: 46.5 cm × 36.0 cm × 14.5 cm
- Weight: 9 kg (net), 11 kg (gross)
BATTERY TESTERS DSF2010-8 20V10A (b11d)
- Voltage Range: 5V to 20V
- Current Output: 0.5A to 10A per channel
- Channel Count: 8 independent channels
- Battery Compatibility: Supports Li-ion, Polymer, NiMH, NiCd, and Lead-acid batteries
- Operation Method: Online
- Communication Port: LAN (TCP/IP protocol)
- Input Power: AC 200V–245V, 50Hz/60Hz
- Dimensions: 675 mm x 340 mm x 160
BATTERY TESTERS DSF40(DK)DSF99V40AMP (2s3a)
- Voltage Range: 9V to 99V
- Charge Current: 0.5A to 20A adjustable
- Discharge Current: 0.5A to 40A adjustable
- Operation Modes: Panel and Software control
- Communication Port: LAN (TCP/IP protocol)
- Input Power: AC 220V ±10%, 50Hz/60Hz
- Display: High-definition LCD screen
- Data Output: Excel format
- Software Compatibility: Windows XP, 7, 8, 10
- Cycle Index: 1 to 16 times
- Protection Features: Power-down protection, reverse connection, over-temperature, over-voltage, short-circuit protection
- Temperature Monitoring: Real-time battery temperature monitoring with automatic shutdown and alarm
- Noise Level: <76 dB
- IP Grade: IP20
- Dimensions: 45 x 48 x 16 cm
BATTERY TESTING LEAD(SF-100-6 23V6A/10A) (1e2c)
- Model SF-100-6
- Voltage Range 0–23V DC
- Current Modes 6A / 10A
- Display Digital LED Display
- Load Type Resistive
- Protection Mechanisms Overcurrent, Overheat, Reverse Polarity
- Operation Mode Manual / Automatic
- Input Power AC 220V / 50Hz
- Dimensions 300mm x 250mm x 150mm
- Weight Approx. 5 kg
BMS LFP 11S 20A DALY (132j)
- Model: Daly BMS LFP 11S 20A Waterproof
- Battery Type: LiFePO4 (LFP)
- Nominal Voltage: 35.2V (11S)
- Balancing Current: 70±25mA
- Charge Voltage: 40.15V
- Discharge Cutoff Voltage: 27.5V
- Continuous Discharge Current: 20A
- Continuous Charge Current: 20A
- Waterproof Rating: IP65
- Operating Temperature: -20°C to 60°C
BMS LFP 11S 20A JBD (HP16SA) (9977)
- Supports 11S LiFePO4 battery configuration
- 20A continuous discharge current
- Nominal voltage: ~35.2V battery pack
- Passive cell balancing
- Over-charge & over-discharge protection
- Short circuit and over-current protection
- Temperature protection with NTC
- Low standby power consumption
- Optional UART / Bluetooth communication
- Compact and lightweight design
BMS LFP 11S 40A DALY (15jc)
- Model: Daly BMS LFP 11S 40A Waterproof
- Battery Type: LiFePO4 (LFP)
- Nominal Voltage: 35.2V (11S)
- Balancing Current: 70±25mA
- Charge Voltage: 40.15V
- Discharge Cutoff Voltage: 27.5V
- Continuous Discharge Current: 40A
- Continuous Charge Current: 40A
- Waterproof Rating: IP65
- Operating Temperature: -20°C to 60°C
BMS LFP 11S 50A TDT TWO PORT (9001)
- Battery Type: LiFePO4 (LFP)
- Configuration: 11S (11 cells in series)
- Nominal Voltage: 35.2V
- Max Charging Voltage: 40.0V – 40.15V
- Continuous Current: 50A
- Peak Current: Higher short-duration tolerance
- Port Type: Two Port (Separate Charge & Discharge)
- Overcharge Detection: ~3.6–3.65V per cell
- Over-discharge Detection: ~2.0–2.5V per cell
- Balancing: Passive balancing
- Operating Temperature: Wide range
BMS LFP 12S 100A DALY (43s5)
- Brand: DALY
- Model: J24K3
- Battery Type: LiFePO4 (LFP)
- Nominal Voltage: 38.4V (12S)
- Balancing Current: 70±25mA
- Charge Voltage: 43.8V
- Discharge Cutoff Voltage: 30V
- Continuous Discharge Current: 100A
- Continuous Charge Current: 100A
- Waterproof Rating: IP65
- Operating Temperature: -20°C to 60°C
BMS LFP 12S 20A DALY (125k)
- Brand: DALY
- Model: J13G3
- Battery Type: LiFePO4 (LFP)
- Nominal Voltage: 38.4V (12S)
- Balancing Current: 70±25mA
- Charge Voltage: 43.8V
- Discharge Cutoff Voltage: 30V
- Continuous Discharge Current: 20A
- Continuous Charge Current: 20A
- Waterproof Rating: IP65
- Operating Temperature: -20°C to 60°C
BMS LFP 12S 30A DALY (37s6)
- Brand: DALY
- Model: J16H3
- Battery Type: LiFePO4 (LFP)
- Nominal Voltage: 38.4V (12S)
- Balancing Current: 70±25mA
- Charge Voltage: 43.8V
- Discharge Cutoff Voltage: 30V
- Continuous Discharge Current: 30A
- Continuous Charge Current: 30A
- Waterproof Rating: IP65
- Operating Temperature: -20°C to 60°C
BMS LFP 12S 40A DALY (35ss)
- Brand: DALY
- Model: J16H3
- Battery Type: LiFePO4 (LFP)
- Nominal Voltage: 38.4V (12S)
- Balancing Current: 70±25mA
- Charge Voltage: 43.8V
- Discharge Cutoff Voltage: 30V
- Continuous Discharge Current: 40A
- Continuous Charge Current: 40A
- Waterproof Rating: IP65
- Operating Temperature: -20°C to 60°C
BMS LFP 15S 100A DALY (1553)
- Brand: DALY
- Model: J24K3
- Battery Type: LiFePO4 (LFP)
- Nominal Voltage: 48V (15S)
- Balancing Current: 70±25mA
- Charge Voltage: 54.75V
- Discharge Cutoff Voltage: 37.5V
- Continuous Discharge Current: 100A
- Continuous Charge Current: 100A
- Waterproof Rating: IP65
- Operating Temperature: -20°C to 60°C
